Diesel engine — working cylinder body (exterior form)

Static view

Reconstructed with machine assistance from Google Patents US542846A. Proportions are authored from the sheet; no dimension is measured or claimed. Rights basis: an expired patent, not yet independently reviewed.

Licence

No licence — the source is claimed under a statutory rights basis, recorded on this page.

Author

reconstructed by Gantry from a cited engineering drawing

The cut shows the outer surface of the model only. The file holds no interior detail, and the cut invents none. What appears inside the cut is the shell of the mesh, not the inside of the machine.

Guided tour

Overview

Licence

No licence — the source is claimed under a statutory rights basis, recorded on this page.

Author

reconstructed by Gantry from a cited engineering drawing

Changes

Changes: this geometry was newly authored from the cited drawing. No part of the source document is reproduced here.

Provenance

Collection: Industrial
Author: reconstructed by Gantry from a cited engineering drawing
Licence: No licence — the source is claimed under a statutory rights basis, recorded on this page.
Clearance: Clear — what this means
Source: https://patents.google.com/patent/US542846A/en
Dimensions: No dimension is stated for this machine, because no source in the ledger establishes one.
Drawing: US542846A — sheet 2 of 5 (Fig. 4, sectional elevation of the single-acting cylinder)
Changes: Changes: this geometry was newly authored from the cited drawing. No part of the source document is reproduced here.

Historical background — not a claim about this model

The cited patent describes a working process before it describes a machine: air compressed until it is hot enough to ignite fuel introduced near the end of the stroke, with combustion paced by the rate of injection rather than by a spark. The efficiency argument rests on the compression ratio, and the compression ratio is what sets the loads the cylinder and its head have to carry.

The sheet shows a single working cylinder with its head and injection arrangement — the part of the engine where the patent’s claims actually live. The remainder of the engine, in the drawing as in the argument, is conventional and is not what was being claimed.

The patent sheet this record cites: US542846A https://patents.google.com/patent/US542846A/en — sheet 2 of 5 (Fig. 4, sectional elevation of the single-acting cylinder); granted 1895-07-16
